Oil Pressure Warning Light for Polaris Models Razrs, Rangers, and Generals

Polaris XP 1000 2014-2018  $95

  Polaris XP 1000 2019-2022  $110



T & C Oil Check System is designed to provide peace of mind for riders

.

There is NO oil pressure indicator light on these models. Riders find themselves stuck with a dead engine due to a lack of oil.

T & C Motorsports has designed the perfect solution. An essential indicator for monitoring the oil pressure and the maintenance of your UTV’s engine.

Simple and easy to use:

Switch ON-Light will turn ON and be Blank

Engine ON-Light will turn OFF after a second if there is a sufficient quantity of oil

The light will remain OFF.

The light will blink (ON and OFF) when lacking 1 quart (liter) or more of oil while driving.



For more information or to order, call 479-434-6034, Monday – Friday 9am – 5pm


PART #                                                  MAKE                                                                    MODEL

   OCS-0008                                            Polaris RZR 800                                                  2010-2014
   OCS-0008                                            Polaris RZR S 800                                                2010-2014

     OCS-0008                                           Polaris Ranger XP 800                                       2010-2014
OCS-0008-4                                         Polaris Ranger 800 Crew4-seater              2010-2014
OCS-0009                                             Polaris RZR XP 900-Crew                               2012-2014
OCS-0009-4                                         Polaris Ranger XP 900 4-seater                   2012-2014
OCS-0008                                             Polaris General                                                 2015-2018
OCS-0008-4                                         Polaris General 4-seater                                2016-2018
OCS-0010-4                                         Polaris General 4-seater                                2019-2022
OCS-0010                                             Polaris General XP 1000                                 2019-2022
OCS-0008                                             Polaris RZR XP 1000                                         2014-2018
OCS-0010                                             Polaris RZR XP 1000                                         2019-2022
OCS-0010-4                                         Polaris RZR 1000 XP                                        2019-2022

If you do not see your model, feel free to contact us during business hours, 9am – 5pm (central time)



DIY INSTRUCTIONS – to accompany instructional video



First, pull your seats and pull the console. Pull the upper dash compartment to get to the ignition switch.

You will need a short 1/2” drill bit -so you don’t have to pull the steering wheel.

Drill the hole so you can see the light from the driver's seat. The right side by the ignition switch seems to be the best place. Run the wire loom through the drilled hole and put the O-ring and nut on the backside of the light.

Connect the RED wire to the ORANGE wire on the back side of the Switch Connector, also labeled D. Run the BLACK wire through the firewall down to the start of the console. Run the wire along with the wiring loom that goes to the back of the motor. Use the wire ties that come in the kit to secure the BLACK wire to the loom.

Run the wire underneath the motor mount up to the starter wires and connect with wire ties. The plug is located on the right side of the motor in line with the oil filter. Remove the plug with a 3/8” ratchet. Install the bushing and the sending unit in the motor with a 7/8” wrench. Do not use the sending unit to tighten the bushing.

Connect BLACK wire to the sending unit.

To test the Oil Check System: Turn the key on, and the light should start blinking on/off until the motor is started.
Once you start the motor, check for any oil leaks.
If you have any questions or problems, please contact T & C Motorsports, 9am- 5pm (central time) at 479-434-6034
PATENT PENDING
